The Hikvision DS-7616NI-Q2 is a professional 16 Channel 4K Network Video Recorder (NVR) designed for medium and large IP surveillance systems. It supports up to 16 IP cameras with recording resolutions up to 8MP and advanced H.265+/H.265 video compression for efficient storage. Featuring dual SATA interfaces with support for up to 16TB total storage, HDMI 4K output, VGA output, Gigabit Ethernet, and Hik-Connect remote access, it provides reliable recording, playback, and remote monitoring.
• Supports up to 16 IP Cameras
• Recording Resolution up to 8MP
• H.265+/H.265/H.264+/H.264 Video Compression
• Live View, Recording & Playback
• 2 SATA Interfaces
• Supports Up to 8TB HDD per Drive
• Maximum Total Storage 16TB
• Gigabit RJ45 Ethernet Port
• Hik-Connect Remote Access
• ONVIF Compatible
• HDMI Output up to 4K
• VGA Output up to Full HD
Offices, Commercial Buildings, Schools, Hospitals, Warehouses, Retail Stores and Professional CCTV Installations.
2 Years Official Warranty.
| Brand | Hikvision |
| Model | DS-7616NI-Q2 |
| Type | 16 Channel NVR |
| Number of Input Channels | 16 |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Recording Resolution | 8MP, 6MP, 5MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Maximum Recording Resolution | 3840 × 2160 (4K) |
| Incoming Bandwidth | Up to 160 Mbps |
| HDMI Output | 4K (3840×2160) @30Hz |
| VGA Output | Up to 1920×1080 @60Hz |
| Network Interface | 1 × RJ45 10/100/1000 Mbps |
| Audio Input | 1 × RCA |
| Audio Output | 1 × RCA |
| Two-Way Audio | Supported |
| SATA Interfaces | 2 |
| Maximum HDD Capacity | Up to 8TB per HDD |
| Maximum Total Storage | 16TB |
| USB Ports | 2 × USB 2.0 |
| Network Protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS |
| Wi-Fi | No |
| Power Supply | 12V DC |
| Power Consumption | ≤15W (Without HDD) |
| Color | Black |
| Warranty | 2 Years |
